- Easily disassembles for transport
- 400 lbs. Weight Capacity
- Includes interchangeable color panels in Red and Blue (Figure A)
- Armrests are padded and adjustable
- Ergonomic throttle control
- Height-adjustable swivel seat with fold-down backrest
- Flat-free, non-marking tires
- Large, plastic carry basket
- Seat position can be adjusted forward or backward
- Front and rear suspension
- Programmable controller
- Easy-to-adjust tiller
- Anti-tip wheels
- Headlight
- Delta tiller
- Easy free wheel operation
| Base Weight | 99 lbs. |
| Batteries (pair) | 12V x 33AH |
| Battery Weight (pair) | 28 lbs. |
| Brakes | Electromagnetic |
| Charger | 4A Offboard |
| Climbing Angle | 7.5° |
| Dimensions | 48" (L) x 25" (W) |
| Floor to Seat Height | 22" - 24" |
| Front Wheels | 10" x 3" Flat-free |
| Ground Clearance | 2.5" |
| HCPCS | K0807 |
| Heaviest Piece Weight | 70 lbs. |
| Maximum Range | 16 miles |
| Motor | 24V x 350W x 5100 rpm |
| Rear Wheels | 10" x 3" Flat-free |
| Seat Dimensions | 18" (W) x 17.5" (D) |
| Seat Type | Folding |
| Seat Weight | 26 lbs. |
| Top Speed | 6 mph |
| Total Weight (excl. hand control) | 153 lbs. |
| Turning Radius | 54" |
| Warranty on Batteries | 12 Months |
| Warranty on Electronic Controller/Drive Train Components | 24 Months |
| Warranty on Frame | Lifetime |
| Weight Capacity | 400 lbs |
| Weight Capacity (13046 | 13046-HD) | 400 lbs. |
